Multi-Mount Continuous Monitor with Mounting Tabs and Universal Power Adapter - Desco 19337

Where the monitor should not sit on the mat, for example under the bench top, on shelving or inside equipment, the Desco Multi-Mount Monitor fits. It continuously monitors the path-to-ground of one operator and one ESD worksurface, and wave distortion technology also verifies the presence of the 1 megohm safety resistor in the wrist strap. The operator test voltage is only 1.2 V.

Key benefits

• Enclosure with mounting tabs for installation on workbenches and in equipment.
• Wrist strap circuit 500 kilohms to 10 megohms, worksurface below 10 megohms to ground.
• ParkSnap with 8 second park delay: park the cord without a false alarm.
• Jack for the 19332 light tower, so alarms are visible from a distance.
• 1.2 V operator test voltage lowers EOS risk, mat monitor switch, adjustable alarm volume.

Applications

Grounding monitoring at ESD workstations and equipment where the monitor is to be mounted out of sight or to the side, for example on benches, test stations or inside machine housings.

Standards

Single-wire impedance design meets ANSI/ESD S20.20 in accordance with ESD TR1.0-01-01. Per ANSI/ESD S1.1 Annex A.3, daily wrist strap testing may be omitted when continuous monitoring is used.
