The Dino-Lite WF4915ZTL ships with the WF-20 Wi-Fi adapter and streams the live image to a tablet, phone or PC without a cable. The built-in polarizer suppresses reflections on metal, glass, plastic and circuit boards. Two year manufacturer warranty, shipped from Germany.
Wireless handheld microscope 1.3 MP 10-140x with polarizer, LWD, AMR, EDOF and EDR, incl. WF-20 - Dino-Lite WF4915ZTL
DINO-LITE
Original product
Net price (excl. VAT)
€945.60
Item
WF4915ZTL
Manufacturer no.
WF4915ZTL
RoHS 2011/65/EU
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.WF4915ZTL
EAN4712805478569
Country of originTaiwan
Customs tariff number90118000
ConditionNew
Article
WF4915ZTL
Frequently Bought Together
-
This Item:
€945.60
-
USB Edge Microscope 5 MP 20-220x with Polarizer and FLC - Dino-Lite AM7115MZT
€758.40
-
X/Y stage table with 360-degree rotating table - Dino-Lite MS15X
€142.80
Total price
The Dino-Lite WF4915ZTL ships with the WF-20 Wi-Fi adapter and streams the live image to a tablet, phone or PC without a cable.
What it does for you
- A 1.3 MP sensor and a 10-140x magnification range, so overview and detail come from the same device.
- The built-in polarizer suppresses reflections on metal, glass, plastic and circuit boards.
- The long working distance leaves room for tweezers, an iron or a probe between optics and object.
- AMR reads the set magnification automatically, so measurements stay correct without recalibrating.
- EDOF stacks images at different focus levels and EDR at different exposures, keeping rough surfaces and hard contrast readable.
- Flexible LED Control switches individual LED segments to take out cast shadows and hot spots.
- The MicroTouch trigger on the housing captures the image without shaking the camera.
Technical data
| Property | Value |
|---|---|
| Magnification | 10x ~ 140x |
| Working distance | Long |
| Macro zoom | No |
| Lens type | Glass with anti-reflection coating |
| Sensor type | CMOS |
| Resolution | 1.3 Megapixel (1280x1024) |
| Frame rate | 30 fps |
| Illumination | White |
| Number of LEDs | 8 |
| LEDs switchable | Yes |
| Flexible LED Control | Yes |
| Polarizer | Yes, linear |
| Infrared filter | IR cut-filter >650 nm |
| Emission filter | No |
| Diffuser cap | Yes (N3C-D included) |
| Magnification readout (AMR) | Yes |
| Extended depth of field (EDOF) | Yes |
| Extended dynamic range (EDR) | Yes |
| Measurement | Yes |
| Calibration | Yes |
| MicroTouch sensor | Yes |
| Magnification lock | Yes |
| Interface | USB 2.0 |
| Imaging standards | DirectShow, UVC |
| Wi-Fi | Yes |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.11.6 and up (cable only) |
| Software | DinoCapture 2.0 (Windows) cable + wireless, DinoXcope (Mac OS) cable only, DinoConnect wireless only |
| Housing | Composite/ plastic housing |
| Dimensions | 11.4cm (L) x 3.3cm (D) |
| Weight | 111g |
| Cable length | 1.8m |
| ESD safe | No |
| Country of origin | Taiwan |
| Warranty | 2 years European warranty |
| Regulatory approval | CE, FCC, ROHS, UKCA - available upon request - [email protected] |
| Package contents | Microscope, WF-20, carry pouch, software CD, calibration target, user manual, N3C-O- Open cap, N3C-C- Closed cap, N3C-D- diffuser cap, N3C-E- extension cap, N3C-L- Long cap, N3C-S- Side light cap |
Magnification, working distance and field of view
| Magnification | Working distance (mm) | Field of view X (mm) | Field of view Y (mm) | Depth of field (mm) |
|---|---|---|---|---|
| 10 | 234.5 | 39.0 | 31.2 | 12 |
| 20 | 112.5 | 19.5 | 15.6 | 4.5 |
| 30 | 72.5 | 13.0 | 10.4 | 3.1 |
| 40 | 54.5 | 9.8 | 7.8 | 1.8 |
| 50 | 43.5 | 7.8 | 6.2 | 1.2 |
| 60 | 37.5 | 6.5 | 5.2 | 0.9 |
| 70 | 33.7 | 5.6 | 4.5 | 0.6 |
| 80 | 31.3 | 4.9 | 3.9 | 0.5 |
| 90 | 29.9 | 4.3 | 3.5 | 0.37 |
| 100 | 29.2 | 3.9 | 3.1 | 0.28 |
| 110 | 29.1 | 3.5 | 2.8 | 0.22 |
| 120 | 29.3 | 3.3 | 2.6 | 0.17 |
| 130 | 29.8 | 3.0 | 2.4 | 0.12 |
| 140 | 30.5 | 2.8 | 2.2 | 0.09 |
Values without front cap, as published by the manufacturer.
Typical uses
- Electronics manufacturing and repair: solder joints, BGA edges, tracks, placement errors.
- Quality control and incoming inspection: surface defects, burrs, coatings, dimensional checks.
- Materials testing: fracture surfaces, welds, corrosion, microstructure.
- Print and textiles: halftone dots, fibre orientation, ink build-up.
| Certification | RoHS 2011/65/EU |
|---|---|
| ESD version | TEC |
| Manufacturer Nr. | WF4915ZTL |
| Manufacturer | Dino-Lite |
| Country of Manufacture | Taiwan |
| EAN | 4712805478569 |
| ESD equipment | USB Mikroskop |
| Weight | 0.111000 |
| HS-Code | 90118000 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Warranty | 2 years |
| Material | ABS plastic |
| Polarizer | Ja |
| Long Working Distance | Ja |
| Interface | USB 2.0 |
