ESD floor tile, conductive, PVC, 500x500x7 mm, pack of 4 - Ecotile

The conductive ESD floor tile from Ecotile creates a permanently dissipative floor for electrostatically protected areas. The dissipative property comes from millions of fine stainless steel fibres dispersed through the entire PVC body, so it never wears away. Installation is adhesive-free using interlocking joints in a click-and-use method, and the tile field is earthed via conductive grounding tape and a grounding tile.

Benefits

• Permanent dissipation from stainless steel fibres dispersed throughout the body
• Adhesive-free click-and-use installation without screed and without downtime
• Fire rating Bfl s1, anti-slip and chemically resistant
• Reduces dust and noise and insulates the floor against cold and moisture

Technical specifications

• Material: PVC with embedded stainless steel fibres
• Dimensions: 500 x 500 x 7 mm
• Colour: grey (RAL 7015)
• Surface: hard, rounded corners
• Surface resistance: 3.0 x 10⁴ to 3 x 10⁶ ohm
• Contact resistance: 3.6 x 10⁵ to 9.5 x 10⁵ ohm
• Fire behaviour: Bfl s1
• Selling unit: pack of 4 (1 m²)

Applications

Electronics manufacturing, cleanrooms, data centres, test and assembly areas requiring a dissipative floor.

Standards

Suitable for ESD floor systems to IEC 61340-5-1, tested to EN 1081, EN 1815 and EN 6356, manufactured under ISO 9001.
