ESD cabinet housing 27x27E, 564x572x850 mm, clear height 750 mm, without drawers, CODE Lock - Lista 95.352

If you want to decide the drawer layout yourself, start with the housing: 564 x 572 x 850 mm outside, 750 mm of clear height inside. With the CODE Lock, a four to six digit number combination replaces the key, and opening and closing is done manually. The housing itself weighs 32 kg, drawers are ordered separately.

Benefits

• Dissipative surface: All painted surfaces carry the dissipative paint coating developed by Lista, which drains charges in a controlled way.
• CODE Lock: four to six digit number combination instead of a key, no key management needed.
• Free configuration: 750 mm of clear height for Lista drawers in the 27 x 27 E format, you decide the layout.
• Can be made mobile: with a matching ESD castor carrier pair, the housing becomes a mobile drawer cabinet.

Colours

Choose the ESD colour when ordering from the following options:

• Light grey RAL 7035
• Pale grey NCS S 2403-Y
• Anthracite grey RAL 7016
• Orange NCS S 1080-Y40R

Use and combination

The housing is used in EPA areas of electronics production, at test and repair stations, in labs and in component stores. The dissipative effect requires proper earthing. It is fitted with Lista drawers in the 27 x 27 E format whose front heights together fill the clear height of 750 mm. To finish the top, an ESD resin cover plate, a grooved mat and a three-sided edge rim are available in the same format. For mobile use there are castor carrier pairs with ESD rubber wheels for lengthwise travel and a four-sided edge rim with push bar.

Notes

Follow Lista's assembly instructions and loading guidelines when loading drawers and drawer cabinets. Load capacity figures apply to an evenly distributed load.
