ESD drawer cabinet 18x27E, 411x572x283 mm, 2 drawers 1x50/1x150, 75 kg, KEY Lock - Lista 93.100

For test stations and repair areas where fixed teams manage their own keys, this Lista cabinet comes with KEY Lock. Its 200 mm clear inside height holds 2 drawers, each with a usable area of 306 x 459 mm and a 75 kg load rating. At just 283 mm high, the cabinet fits under a worktop or on top of a workbench.

Benefits

• Dissipative surface: All painted parts carry the dissipative paint coating developed by Lista, which drains charges in a controlled way.
• KEY Lock: The interchangeable cylinder can be swapped if a key goes missing.
• 75 kg per drawer: usable area of 306 x 459 mm per drawer, enough for heavy test equipment and tools.
• Single-drawer interlock: As standard only one drawer can be opened at a time, which keeps the cabinet stable when drawers are pulled out.

Colours

Choose the ESD colour when ordering from the following options:

• Light grey RAL 7035
• Pale grey NCS S 2403-Y
• Anthracite grey RAL 7016
• Orange NCS S 1080-Y40R

Use and combination

Typical locations are EPA areas in electronics production and at EMS providers, test and repair stations, labs and component stores. The dissipative effect depends on the cabinet being properly earthed. Lista partitioning material in the 18 x 27 E grid divides the drawers for small parts, and the cabinet can be lined up with other Lista elements of the same width.

Notes

Follow Lista's assembly instructions and loading guidelines when loading the drawers and the cabinet. The stated load capacity applies to an evenly distributed load.
