Floor Scale 600 kg / 1500 kg Readability 0,2 kg / 0,5 kg - KERN BIC 1T-4
KERN BIC 1T-4 multi-range floor scale, 600 kg / 1500 kg with 0,2 kg / 0,5 kg readability on 1200×1500 mm. Non-slip steel chequer plate, IP67 load cells and simple 4-key operation at an attractive price.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The KERN BIC 1T-4 weighs pallets and containers up to 1500 kg and, as a multi-range scale, switches automatically between two ranges with a fine 0,2 kg resolution in the lower one. The non-slip steel chequer-plate bridge measures 1200×1500 mm.
Benefits
- High resolution 2×3000 divisions: automatic switching 600 kg / 1500 kg with 0,2 kg / 0,5 kg readability, fine at low load and high capacity at heavy.
- Non-slip weighing bridge: welded steel chequer plate with lifting holes for cleaning.
- IP67 protection: four silicone-coated steel load cells for industrial use.
- Simple 4-key operation: fast to use with no training, wall bracket for the terminal as standard.
- Mains-independent operation: battery function with 4 AA cells, up to 60 h of use.
- Strong price-performance: high resolution and IP67 build at an economical price.
Applications
Industry and production, warehouse logistics, packaging, the automotive sector, and logistics and dispatch.
Compliance and origin
Compliant with CE and RoHS. Country of manufacture China. EAN 4045761193178, customs code 84238220.
Technical data
| Weighing range (Max) | 600 kg; 1500 kg |
|---|---|
| Readability (d) | 0,2 kg; 0,5 kg |
| Repeatability | 0,2 kg; 0,5 kg |
| Linearity | ± 0,6 kg; 1,5 kg |
| Weighing system | Dehnungsmessstreifen |
| Stabilisation time | 2 s |
| Weighing area (W×D) | 1200×1500 mm |
| Platform height | 108 mm |
| Display | LCD |
| Digit height | 25 mm |
| Weighing units | kg; lb |
| Cable length | 5 m |
| Battery runtime | 60 h |
| Power supply | Netzteil & Batteriefunktion (Batterie nicht enthalten) |
| Net weight | 150 kg |
| Operating temperature | -10 to 40 °C |
| Weight | 170.000000 |
| Manufacturer | Kern |
| EAN | 4045761193178 |
| HS-Code | 84238220 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Wägebereich max (g) | 1500000.000000 |
| Ablesbarkeit (g) | 200.000000 |
| Display type | LCD |
| Weighing system | Strain gauge |
