Floor Scale 600 kg / 1500 kg Readability 0,2 kg / 0,5 kg - KERN BIC 1T-4S

The KERN BIC 1T-4S brings the multi-range technology of the BIC series to a compact 1000×1000 mm platform and weighs up to 1500 kg with a fine 0,2 kg resolution in the lower range. The small footprint fits tight workstations.

Benefits

• High resolution 2×3000 divisions: switching 600 kg / 1500 kg with 0,2 kg / 0,5 kg readability.
• Compact footprint: 1000×1000 mm bridge for cramped workstations.
• Non-slip weighing bridge: welded steel chequer plate with lifting holes.
• IP67 protection: four silicone-coated steel load cells for industrial use.
• Simple 4-key operation: wall bracket for the terminal as standard.
• Battery operation: 4 AA cells, up to 60 h mains-independent.

Technical data

• Weighing range (Max): 600 kg; 1500 kg
• Readability (d): 0,2 kg; 0,5 kg
• Repeatability: 0,2 kg; 0,5 kg
• Linearity: ± 0,6 kg; 1,5 kg
• Weighing system: Dehnungsmessstreifen
• Stabilisation time: 2 s
• Weighing area (W×D): 1000×1000 mm
• Platform height: 108 mm
• Display: LCD
• Digit height: 25 mm
• Weighing units: kg; lb
• Cable length: 5 m
• Battery runtime: 60 h
• Power supply: Netzteil & Batteriefunktion (Batterie nicht enthalten)
• Net weight: 70 kg
• Operating temperature: -10 to 40 °C

Applications

Industry and production, warehouse logistics, packaging, the automotive sector, and logistics and dispatch.

Compliance and origin

Compliant with CE and RoHS. Country of manufacture China. EAN 4045761193185, customs code 84238220.
