Counting Scale 15000 g Readability 5 g - KERN CXB 15K5NM
The KERN CXB 15K5NM is a counting scale with a 15000 g weighing range and 5 g readability for fast piece counting. A counting resolution of 30,000 points and three separate displays for weight, reference weight and quantity speed up stocktaking, order picking and goods receipt.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For anyone who needs to count small parts quickly and reliably, the KERN CXB 15K5NM is a compact bench scale: it counts across a weighing range up to 15000 g at 5 g readability and shows weight, reference weight and total quantity at the same time.
Benefits
- Counting resolution of 30,000 points: precise counting even of small quantities at 5 g readability
- Three displays: weight, reference weight and total quantity visible in parallel
- Two scales in one: switch from counting to weighing mode at the press of a button
- Integrated ESD protection: suitable for weighing electrostatically sensitive small plastic parts
- Automatic reference optimisation: the average part weight is refined step by step, plus 10 memory slots for reference weights
- Verifiable ex works: accuracy class III, verification value e = 5 g, minimum load 100 g for legally compliant weighing
- Mains-independent operation: built-in Pb battery for up to 200 h of use, ideal for changing locations in production, warehouse and dispatch
Applications
Warehouse logistics; packaging industry; retail; counting tasks; order picking and stocktaking.
Compliance and origin
Conformity assessment to accuracy class III available (verification value e, see technical data). EAN 4045761162648. Customs tariff number 84238129. Country of origin: China.
Technical data
| Weighing range (Max) | 15000 g |
|---|---|
| Readability (d) | 5 g |
| Verification value (e) | 5 g |
| Accuracy class | III |
| Minimum load (Min) | 100 g |
| Repeatability | 5 g |
| Linearity | ± 10 g |
| Smallest part weight (laboratory conditions) | 5 g |
| Smallest part weight (normal conditions) | 50 g |
| Weighing system | Strain gauge |
| Stabilisation time | 2 s |
| Housing material | Plastic |
| Weighing surface (W x D) | 300×225 mm |
| Housing dimensions (W x D x H) | 300×330×110 mm |
| Display | LCD |
| Digit height | 18 mm |
| Weighing units | kg; g |
| Power supply | Rechargeable battery and mains adapter |
| Battery type | Pb |
| Net weight | 3,8 kg |
| Operating temperature | -10 °C to 40 °C |
| Weight | 6 kg |
| Manufacturer | Kern |
| EAN | 4045761162648 |
| HS-Code | 84238129 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Material | Plastic |
| Wägebereich max (g) | 15000 |
| Ablesbarkeit (g) | 5 |
| Display type | LCD |
| Verification class | III |
