Digital Microscope Set 4x - KERN OBE 134C825

When specimens under the microscope need to be documented and reviewed as a team, a complete digital set is the answer. The KERN OBE 134C825 combines the trinocular OBE stand with the KERN ODC 825 C-mount camera, 5,1 MP, CMOS sensor 1/2,5 inch into a ready-to-use live solution at magnifications up to 1000x. The 100x objective additionally reveals fine cellular detail.

Benefits

• Digital live examination: KERN ODC 825 C-mount camera, 5,1 MP, CMOS sensor 1/2,5 inch
• Direct evaluation: live transfer to the PC with the supplied Microscope VIS software and a stage micrometer for calibration
• Even lighting: continuously dimmable 3 W LED transmitted illumination
• Clear optics: achromatic 4x / 10x / 40x / 100x objectives, 10x eyepiece with an 18 mm field of view
• Connectivity: USB 2.0
• Fully supplied: including dust cover, eyecups and a multilingual manual

Technical data

• Tube: trinocular, inclined 30°
• Objectives: 4x / 10x / 40x / 100x, achromatic
• Eyepiece: 10x, field of view 18 mm
• Illumination: 3 W LED, transmitted
• Optical system: finite
• Interpupillary distance: 50 - 75 mm
• Light-path split: 20:80
• Camera: ODC 825, 5,1 MP, 1/2,5 inch
• Interfaces: USB 2.0
• Power supply: mains adapter 100 V - 240 V
• Net weight: 6 kg

Applications

Designed for school, training and laboratory: live viewing, image and video documentation of translucent, thin and high-contrast specimens.

Compliance and origin

EAN 4045761356795, customs tariff number 90118000, origin China.
