Digital Microscope Set 4x - KERN OBN 142C861
Ready-to-use KERN OBN 142C861 digital microscope set combining an infinity microscope with an adapted camera (20 MP). Live view, documentation and measurement over USB 3.0, software included. Objectives 4x / 10x / 20x / 40x / 100x.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The KERN OBN 142C861 is a ready-to-use digital microscope set: the trinocular OBN 142 fluorescence microscope (5 W LED reflected and 3 W LED transmitted light) with an adapted KERN ODC 861 C-mount camera. The camera streams the live image straight to the PC. The supplied KERN Microscope VIS Basic software with a stage micrometer enables calibration, image documentation and measurement. Objectives 4x / 10x / 20x / 40x / 100x reach 40x to 1000x with the 10x eyepiece.
Benefits
- Fluorescence and transmitted light: 5 W LED reflected fluorescence plus 3 W LED transmitted light on one stand
- Live imaging and documentation: ODC 861 (20 MP, Sony CMOS, 1")
- Ready to connect: interfaces USB 3.0
- Plane infinity optics: Infinity Plan objectives 4x / 10x / 20x / 40x / 100x
- Matching adapter included: C-mount adapter included, powered over the USB cable
- Köhler illumination: professional Köhler illumination with 1,25 Abbe condenser
Compliance and origin
EAN 4045761490901. Customs tariff number 90118000. Country of origin China.
Technical data
| Optical system | Infinity |
|---|---|
| Objective class | Infinity Plan |
| Objectives | 4x / 10x / 20x / 40x / 100x |
| Tube | Trinokular |
| Tube inclination | 30° |
| Eyepiece | 10x |
| Eyepiece field of view | 20 mm |
| Interpupillary distance | 50 mm - 75 mm |
| Nosepiece positions | 5 |
| Reflected-light illumination | LED, 5W |
| Transmitted-light illumination | LED, 3W |
| Light-path split | 0:100,80:20 |
| Camera resolution | 20 MP |
| Camera sensor | Sony CMOS, 1" |
| Interfaces | USB 3.0 |
| Power supply | Netzteil (100 - 240 V) |
| Net weight | 11 kg |
| Weight | 14.000000 |
| Manufacturer | Kern |
| EAN | 4045761490901 |
| HS-Code | 90118000 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Interface | USB |
