Inverted Microscope - KERN OCM 167
The KERN OCM 167 inverted fluorescence microscope runs entirely on LED technology: a 5 W LED transmitted source for brightfield and a 5 W LED epi-fluorescence unit for excitation. Its Abbe condenser with 72 mm working distance and trinocular tube suit living cell cultures in culture vessels. At 16 kg net weight with a detachable USB power supply, it is low-maintenance and easy to relocate.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For labs that prefer mercury-free illumination, the KERN OCM 167 offers an all-LED approach: a 5 W LED in transmitted light for brightfield and a 5 W LED epi-fluorescence unit for excitation. The Abbe condenser (N.A. 0,3) with 72 mm working distance leaves room for culture vessels under the objective.
Benefits
- All-LED technology: 5 W LED fluorescence excitation and 5 W LED transmitted light, no HBO burner.
- Long working distance: Abbe condenser N.A. 0,3 with 72 mm clearance for flasks, dishes and microtitre plates.
- Trinocular tube: parallel camera port via C-mount adapter while viewing.
- Infinity Plan optics: plan-corrected 10x, 20x, 40x objectives plus PH 20x phase contrast.
- Detachable USB power supply: USB plug-in adapter, low net weight of 16 kg.
Applications
Research and cultivation of cell and tissue cultures, plus observation of translucent, low-contrast specimens such as living mammalian cells, immunofluorescence and DAPI staining.
Compliance and origin
EAN 4045761478329, customs tariff number 90118000, country of origin China.
Technical data
| Optical system | Infinity |
|---|---|
| Tube | trinocular, 45 degree inclination |
| Objectives | Infinity Plan 10x / 20x / 40x / PH 20x |
| Eyepiece | HWF 10x / 22 mm, high eye point |
| Field of view | 22 mm |
| Interpupillary distance | 48 - 76 mm |
| Reflected illumination | LED 5 W (fluorescence) |
| Transmitted illumination | LED 5 W |
| Nosepiece | 5 positions |
| Net weight | 16 kg |
| Weight | 20 kg |
| Manufacturer | Kern |
| EAN | 4045761478329 |
| HS-Code | 90118000 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
