Inverted Microscope - KERN OCM 166

Observing cell cultures from below in flasks, dishes or microtitre plates calls for working distance and a fluorescence excitation strong enough to reveal faint signals. The KERN OCM 166 delivers both: a 100 W HBO epi-fluorescence unit and an Abbe condenser (N.A. 0,3) with 72 mm working distance for brightfield, phase contrast and fluorescence.

Benefits

• Fluorescence and brightfield combined: 100 W HBO reflected light for excitation plus a continuously adjustable 30 W halogen transmitted light.
• Long working distance: Abbe condenser N.A. 0,3 with 72 mm clearance for culture vessels under the objective.
• Trinocular tube: parallel camera port via C-mount adapter while viewing.
• Infinity Plan optics: plan-corrected 10x, 20x, 40x objectives plus PH 20x phase contrast for low-contrast specimens.
• Ergonomic build: stable stand and mechanical stage with specimen holder (110 mm diameter).

Technical data

• Optical system: Infinity
• Tube: trinocular, 45 degree inclination
• Objectives: Infinity Plan 10x / 20x / 40x / PH 20x
• Eyepiece: HWF 10x / 22 mm, high eye point
• Field of view: 22 mm
• Interpupillary distance: 48 - 76 mm
• Reflected illumination: HBO 100 W (fluorescence)
• Transmitted illumination: halogen 30 W
• Nosepiece: 5 positions
• Net weight: 22 kg

Applications

Research and cultivation of cell and tissue cultures, plus observation of translucent, low-contrast specimens such as living mammalian cells, immunofluorescence and DAPI staining.

Compliance and origin

EAN 4045761476233, customs tariff number 90118000, country of origin China.
