Inverted Microscope - KERN OCM 168

The KERN OCM 168 is aimed at stationary laboratory and healthcare facilities that want inverted fluorescence with low-maintenance LED illumination. A 5 W LED in transmitted light and a 5 W LED epi-fluorescence unit cover brightfield, phase contrast and fluorescence, while the Abbe condenser (N.A. 0,3) provides 72 mm working distance.

Benefits

• All-LED technology: 5 W LED fluorescence excitation and 5 W LED transmitted light, no HBO burner.
• Long working distance: Abbe condenser N.A. 0,3 with 72 mm clearance for culture vessels.
• Trinocular tube: parallel camera port via C-mount adapter.
• Infinity Plan optics: plan-corrected 10x, 20x, 40x objectives plus PH 20x phase contrast.
• Practical equipment: mechanical stage with specimen holder (110 mm diameter), dust cover included.

Technical data

• Optical system: Infinity
• Tube: trinocular, 45 degree inclination
• Objectives: Infinity Plan 10x / 20x / 40x / PH 20x
• Eyepiece: HWF 10x / 22 mm, high eye point
• Field of view: 22 mm
• Interpupillary distance: 48 - 76 mm
• Reflected illumination: LED 5 W (fluorescence)
• Transmitted illumination: LED 5 W
• Nosepiece: 5 positions
• Net weight: 17 kg

Applications

Research and cultivation of cell and tissue cultures, stationary and clinical laboratory facilities, and public health offices. Observation of translucent, low-contrast specimens such as living mammalian cells, immunofluorescence and DAPI staining.

Compliance and origin

EAN 4045761263536, customs tariff number 90118000, country of origin China.
