Microscope - KERN ODC 874
The KERN ODC 874 turns an ordinary microscope into a digital one: the eyepiece camera replaces an eyepiece and connects to the computer over USB 2.0. The 3,1 MP Aptina CMOS sensor transfers the image without a separate mains adapter, drawing power from the USB cable. Adapters for tube diameters of 23,2, 30,0 and 30,5 mm are included.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
To upgrade an existing, non-digital microscope, the KERN ODC 874 simply replaces an eyepiece. Over USB 2.0 the 3,1 MP Aptina CMOS sensor sends its image to the computer, with the USB cable supplying power.
Benefits
- Upgrade without conversion: eyepiece camera replaces an existing eyepiece and digitises the microscope.
- USB operation without adapter: powered by the USB 2.0 cable.
- Matching adapters: for tube diameters 23,2 mm (standard), 30,0 mm and 30,5 mm included.
- 3,1 MP Aptina CMOS: stable image performance for measurement, counting and documentation.
- Complete accessories: Microscope VIS OXM 901 software, USB cable (1,5 m) and stage micrometer for calibration.
Applications
Digitising existing microscopes for measurement, counting, documentation, archiving and image processing.
Compliance and origin
EAN 4045761190528, customs tariff number 85258900, country of origin China.
Technical data
| Camera resolution | 3,1 MP |
|---|---|
| Sensor type | Aptina CMOS |
| Sensor size | 1/2,5 inch |
| Interface | USB 2.0 |
| Tube diameters | 23,2 / 30,0 / 30,5 mm |
| Power supply | via USB cable |
| Net weight | 0,45 kg |
| Weight | 0.5 kg |
| Manufacturer | Kern |
| EAN | 4045761190528 |
| HS-Code | 85258900 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
