LEANLED II Basic-Line LED Machine Light 1020 mm, 23.1W, 5700K, IP54 - LED2WORK 111010-56

The LEANLED II Basic-Line brings affordable, functional machine and workplace lighting to cost-sensitive jobs such as control cabinet construction and the wider industrial environment. At 1020 mm it produces 3570 lm from 23.1 W.

Key benefits

• High efficiency of 155 lm/W saves energy across its service life
• Opal-white cover delivers low-glare, even light over 120 degrees
• Daylight-white 5700K light with Ra >80 for accurate detail work
• Sturdy aluminium housing rated IP54 for demanding machine use
• Long service life of more than 60,000 h (L80/B10)
• Pivoting and fixed brackets included for mounting

Technical data

• Model: LEANLED II Basic-Line opal white
• Design: LED surface-mounted machine light
• Light source: SMD LED
• Power: 23.1 W
• Luminous flux: 3570 lm
• Luminous efficacy: 155 lm/W
• Light colour: 5700K (3-step MacAdam)
• Colour rendering (Ra): >80
• Beam angle: 120 degrees
• Supply voltage: 24V DC
• Connection: M12 A-coded, 3-pin
• Protection rating: IP54
• Protection class: III
• Operating temperature: 0 °C to +45 °C
• Service life: > 60,000 h (L80/B10)
• Housing material: aluminium
• Cover material: polycarbonate
• Dimensions: length 1020 mm, 31 mm x 26 mm
• Weight: 780 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA
• Made in: Germany

Applications

Suited to lighting control cabinets, machines and work areas in industry wherever a budget-conscious, durable luminaire is needed.

Note: undervoltage (< 24V DC) reduces the luminous flux.
