M12 T-splitter 3-pole A-coded, 24V DC, max. 6 A - LED2WORK 200200-07

Images are examples, some edited with AI. The technical data are authoritative. AI notice

M12 T-splitter 3-pole A-coded, 24V DC, max. 6 A - LED2WORK 200200-07

Name: M12 T-splitter 3-pole A-coded, 24V DC, max. 6 A - LED2WORK 200200-07
Brand: LED2WORK
SKU: L2W-200200-07
Price: 39.95 EUR
Availability: InStock

LED2WORK ✓ Original product Brand new Made in Germany

Rugged M12 T-splitter that connects two 24V DC LED luminaires to a single power supply. A-coded and rated for 6 A, ideal for splitting installations in tight spaces.

Net

€39.95

excl. VAT

Item L2W-200200-07

Manufacturer no. 200200-07

Question about this item

Datasheet (PDF) 4 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The M12 T-splitter is a low-cost, space-saving way to connect two LED2WORK luminaires to a single 24V DC supply. The A-coded splitter runs from one M12 socket to two M12 sockets and one M12 plug and suits the splitting of sensor and actuator installations.

Benefits

Connects two 24V DC LED luminaires to one supply, saving wiring and space
Rated for 6 A, A-coded to prevent mismating
Nickel-plated CuZn metal body with gold-plated contacts for reliable contact
IP54 protection when mounted

Applications

For splitting 24V DC installations, for example to connect two machine or signal lights to a shared power supply. The supply power must exceed the demand of both luminaires and the load must not exceed 6 A.

Technical data

Model	connection accessory
Design	T-piece / distribution box
Configuration	M12 socket to M12 plug and M12 socket
Coding	A-coded
Operating voltage	24V DC
Rated voltage	60V AC/DC
Current rating	6 A
Connection	screw terminal
Protection rating (mounted)	IP54
Operating temperature	-30 °C to +80 °C
Insulation resistance	>= 100 million Ohm
Material	nickel-plated CuZn coupling nut, gold-plated CuZn contacts, plastic housing
Weight	50 g
Made in	Germany
Manufacturer	LED2WORK
Manufacturer Nr.	200200-07
HS-Code	85366990
GPSR manufacturer information	LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Beam angle	30°
Protection class (IP)	IP54
