M12 Y-splitter with 2x 1 m lead, A-coded, 24V DC, 4 A - LED2WORK 200200-08

The M12 Y-splitter is a simple way to connect two LED2WORK luminaires to a single 24V DC supply. With one M12 plug and two M12 sockets on 1 m PUR cables each, two luminaires can be wired directly from the supply socket.

Benefits

• Two fixed 1 m leads, no extra field wiring required
• Rated for 4 A, A-coded to prevent mismating
• PUR cable and nickel-plated CuZn body, sealed up to IP68 when mounted
• Wide temperature range from -30 °C to +80 °C

Technical data

• Model: connection accessory
• Design: Y-splitter with cable
• Configuration: M12 plug to 2x M12 socket
• Cable length: 2x 1 m
• Coding: A-coded, 3-pole
• Operating voltage: 24V DC
• Rated voltage: 60V AC/DC
• Current rating: 4 A
• Connection: screw terminal
• Protection rating (mounted): IP65, IP67, IP68
• Operating temperature: -30 °C to +80 °C
• Material: PUR cable, nickel-plated CuZn coupling nut, CuZn contacts, plastic housing
• Weight: 200 g
• Made in: Germany

Applications

For connecting two 24V DC machine or signal lights to a shared power supply. The supply power must exceed the demand of both luminaires and the load must not exceed 4 A.
