M12 Y-splitter with 2x 2 m lead, A-coded, 24V DC, 4 A - LED2WORK 200200-09
M12 Y-splitter with two 2 m flying leads connects two 24V DC LED luminaires to one supply. A-coded, 4 A, sealed PUR cable rated up to IP68.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The M12 Y-splitter is a simple way to connect two LED2WORK luminaires to a single 24V DC supply. With one M12 plug and two M12 sockets on 2 m PUR cables each, it bridges larger distances between luminaire and supply.
Benefits
- Two fixed 2 m leads for greater reach
- Rated for 4 A, A-coded to prevent mismating
- PUR cable and nickel-plated CuZn body, sealed up to IP68 when mounted
- Wide temperature range from -30 °C to +80 °C
Applications
For connecting two 24V DC machine or signal lights to a shared power supply over greater distances. The supply power must exceed the demand of both luminaires and the load must not exceed 4 A.
Technical data
| Model | connection accessory |
|---|---|
| Design | Y-splitter with cable |
| Configuration | M12 plug to 2x M12 socket |
| Cable length | 2x 2 m |
| Coding | A-coded |
| Operating voltage | 24V DC |
| Rated voltage | 60V AC/DC |
| Current rating | 4 A |
| Connection | screw terminal |
| Protection rating (mounted) | IP65, IP67, IP68 |
| Operating temperature | -30 °C to +80 °C |
| Material | PUR cable, nickel-plated CuZn coupling nut, CuZn contacts, plastic housing |
| Weight | 300 g |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 200200-09 |
| HS-Code | 85366990 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Beam angle | 30° |
| Protection class (IP) | IP68 |
