SYSTEMLED EVO controller dimmer/switch, 3 m cable, IP54 - LED2WORK 240700-01

The SYSTEMLED EVO controller lets you dim a SYSTEMLED EVO luminaire steplessly and switch it on and off from a distance. The 3 m cable and IP54 protection rating allow it to be placed directly in the working area, separate from the luminaire.

Key benefits

• Stepless dimming from 100 down to 10 % brightness
• Integrated on/off switch for direct operation
• 3 m cable for flexible positioning at the workstation
• IP54 protection rating for use in harsh industrial environments
• Sturdy housing of ABS and PES

Technical data

• Model: SYSTEMLED EVO accessory
• Cable length: 3 m
• Material: ABS and PES
• On/off switch: yes
• Driver: external
• Dimmable: yes, stepless (100-10 %)
• Protection rating: IP54, protection class III
• Operating temperature: -20 °C to +50 °C
• Storage temperature: -20 °C to +80 °C
• Dimensions: 122 mm x 38 mm x 29 mm
• Weight: 250 g
• Certifications: CE, UKCA
• Made in: Germany

Applications

For external brightness control of SYSTEMLED EVO luminaires at machine and assembly workstations. Not suitable for the SurfaceOne.
