TSOP-56 Pik-Tip 14.2 x 19.3 mm for Sodr-X-Tractor SX - PACE 1121-0569

Name: TSOP-56 Pik-Tip 14.2 x 19.3 mm for Sodr-X-Tractor SX - PACE 1121-0569
Brand: PACE
SKU: PC-1121-0569
Price: 67.90 EUR
Availability: InStock

PACE ✓ Original product Brand new Made in United States

TSOP-56 Pik-Tip, 14.2 x 19.3 mm, the widest TSOP tip for the PACE Sodr-X-Tractor SX-70 to SX-100. It removes TSOP-56 devices one-handed with its integral vacuum pick.

Net

€67.90

excl. VAT

Item PC-1121-0569

Manufacturer no. 1121-0569

Question about this item

Datasheet (PDF) 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

With 56 leads and a 14.2 mm width, the TSOP-56 needs a tip that heats a large area evenly. This Pik-Tip, 14.2 x 19.3 mm (0.560 x 0.760 in), melts both lead rows together, then the pick takes up the package using the station vacuum.

Benefits

14.2 x 19.3 mm, the widest of the TSOP Pik-Tips
Even heat across all 56 leads
One-handed lift-off without prying at the pads

Specifications

Applications

Replacing high capacity TSOP-56 flash devices
Repair of memory and controller boards

Compatibility

SX-100 Sodr-X-Tractor IntelliHeat (6010-0149)
SX-90, SX-80 and SX-70 Sodr-X-Tractor

Technical data

Part number	1121-0569
Type	Pik-Tip, SMD removal tip with vacuum pick
Package	TSOP-56
Size A x B	14.2 x 19.3 mm
Handpiece	PACE SX-100, SX-90, SX-80, SX-70
Sales unit	1 piece
Weight	0.01 kg
Manufacturer	PACE
Manufacturer Nr.	1121-0569
HS-Code	85159080
GPSR manufacturer information	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Condition of article	New
Article authenticity	Original product
Country of Manufacture	United States
Tip diameter/width [mm]	14.2
Soldering tip shape	sonstige
Series	SX-90/SX-100
