Funnelet for Reinforcing Stressed Through-Holes - PACE 1347-0010

Name: Funnelet for Reinforcing Stressed Through-Holes - PACE 1347-0010
Brand: PACE
SKU: PC-1347-0010
Price: 0.47 EUR
Availability: InStock

PACE ✓ Original product Brand new Made in United States

PACE funnelet that lines holes at mechanically stressed points such as connectors or heavy components with metal. This way the solder joint holds again after the repair.

Net

€0.47

excl. VAT

Item PC-1347-0010

Manufacturer no. 1347-0010

Question about this item

Datasheet (PDF) 2 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Pads at connectors, switches or heavy leaded components tear out easily because pulling and mating forces act on the hole. A set funnelet 1347-0010 lines the hole and gives the new solder joint a firm seat.

Benefits

Metal lining of the hole for a stronger hold
Flange on the component side supports the pad
Usable with the PACE setting tools as a Cir-Kit accessory

Specifications

Applications

Repairing torn-out pads at connectors
Holes of heavy leaded components

Technical data

Manufacturer part number	1347-0010 (PACE P/N 1347-0010-P100)
Type	Funnelet, funnel-shaped eyelet
Related kits	Cir-Kit Basic 6993-0037, Advanced 6993-0077, Master 6993-0082
Dimensions	not specified, select by part number
Sales unit	1 piece
Weight	0.05 kg
Manufacturer	PACE
Manufacturer Nr.	1347-0010
HS-Code	85159080
GPSR manufacturer information	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Condition of article	New
Article authenticity	Original product
Country of Manufacture	United States
