Arm-Evac 150 Digital Fume Extractor with SteadyFlex Arm - PACE 8889-0155

Flux fumes should be captured at the source, not left to the central air handling system. The PACE Arm-Evac 150 extracts up to 280 m³/h right at the joint while running at just 55 dBA. The system comes with everything one operator needs: self-supporting ESD-safe SteadyFlex arm and nozzle, wireless remote control and 3-stage filtration.

The low-profile 20-gauge steel housing fits under most benches. A brushless motor pump needs no costly routine maintenance, and a filter condition monitor with alarm warns of blockage or a due filter change. With a second SteadyFlex arm the unit serves two operators.

Benefits

• SteadyFlex arm stays exactly where you position it, 60 mm diameter, 132 cm length
• 10 airflow speed settings with LED indicator, time set feature for automatic shut-off
• Filter condition monitor with alarm and total run time counter for planned filter changes
• Control panel lock prevents unauthorized changes
• Wireless remote operates most functions from a distance

Specifications

Applications

• Hand soldering and rework at electronics benches
• Light extraction during handheld drilling, milling or grinding
• Odor reduction with limited use of adhesives and solvents

Contents

• SteadyFlex arm and nozzle assembly (8886-0850)
• Inlet cap (8884-0152)
• Wireless remote control (8884-0153), CR2025 battery not included
• Casters, set of 4 (8884-0151)

Compatible accessories

• ESD-safe nozzle/endpiece 8884-0154
