MicroClick-Drehmomentschrauber MC 10, 2-10 Nm, 1/4" - Proxxon 23348
Torque screwdriver for 2 to 10 Nm with a clearly audible and palpable click signal. A micro scale (1 rotation = 2.0 Nm, 0.2 Nm graduation) gives exact setting, and the 1/4" rear connector takes the supplied T-handle for higher torques.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The MicroClick MC 10 is a torque screwdriver for the 2 to 10 Nm range. When the preset torque is reached it releases automatically and gives a clearly audible and palpable click signal.
- Fine adjustment via micro scale: one rotation equals 2.0 Nm and the scale ring is graduated in 0.2 Nm, plus a clearly legible window scale.
- 1/4" rear connector for the supplied T-handle with sliding bar, to apply torques above the 6 to 8 Nm reachable by hand.
- 1/4" square drive (6.3 mm) for holding sockets.
- Adapter with spring sleeve included for a form-fitting hold of 1/4" standard bits.
Technical data
| Torque range | 2 to 10 Nm |
|---|---|
| Fine graduation | 1 rotation = 2.0 Nm, scale ring 0.2 Nm |
| Accuracy | +/- 6 % |
| Drive | 1/4" square (6.3 mm), 1/4" rear connector for T-handle |
| Total length | 165 mm |
| Weight | approx. 270 g |
| Manufacturer | Proxxon |
| Manufacturer Nr. | 23348 |
| EAN | 4006274233485 |
| HS-Code | 82041100 |
| GPSR manufacturer information | PROXXON S.A. Härebierg 6-10, LU-6868 Wecker, www.proxxon.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
| ESD version | TEC |
Suited to precise fasteners in the workshop, precision mechanics and model making. T-handle and plastic case are included.
