Kartuschenlötspitze für TS8, abgewinkelt 30°, kurzer Kegel, nadelspitz Ø 0,2 mm rund, 2 mm Lot-benetzt - Quick TSS08-J01

Approaching a board steeply with a straight tip means the iron body hides the very pad it has to hit. The TSS08-J01 answers with a 30 degree bend, the 0.2 mm needle points at the joint while the iron sits flatter in the hand.

What the geometry does

• 30 degree bend gives a flatter working angle and a clear view of pad and component lead.
• Needle point of 0.2 mm places the heat on one pad rather than on its neighbours.
• Short cone behind the needle keeps the mass close to the crown and buffers the heat draw on contact.
• Tinned length of 2 mm keeps the solder in the point zone, which limits the volume applied per joint.
• Thermocouple in the tip lets the loop react at the working face instead of late in the heater.
• Chip with the stored calibration value returns the same displayed temperature after every tip change.

Technical data

Application, scope of delivery and compatibility
