The 1.2 mm chisel of the TSS11 range is the everyday tip at the bench, wide enough for component leads and still narrow enough for pads on a grid. Blade thickness 0.8 mm, overall length 90 mm, 100 to 450 °C on the TS11 and 300 °C in three seconds.
Kartuschenlötspitze TS11 gerade Meißel 1,2 mm - extrem schnelle Aufheizzeit - Quick TSS11-1.2D
QUICK
Original product
Net price (excl. VAT)
€6.30
Item
QCK-TSS11-1.2D
Manufacturer no.
TSS11-1.2D
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TSS11-1.2D
ConditionNew
Article
QCK-TSS11-1.2D
Frequently Bought Together
If only one tip is going to live in the holder, it is usually the middle size. This cartridge, 1.2 mm wide on a 0.8 mm blade, handles pads, pins and connectors without a change and stands at 300 °C three seconds after start on the TS11.
Why the middle size covers the day
- 1.2 mm of working width provides enough contact area for component leads while staying under the pitch of common connectors.
- A 0.8 mm blade carries more stored heat than the 0.6 mm of the TSS11-0.8D, which shows on stranded wire and through-hole pins.
- Heat-up of three seconds from 20 °C to 300 °C, so there is effectively no wait at the start of a shift.
- Temperature range of 100 to 450 °C on the TS11, which includes lead free alloys.
- Tip and heater form one unit and the integrated thermocouple measures where the heat is actually drawn off.
- Overall length 90 mm and tool free changing, so the handpiece stays manageable and swaps are quick.
Technical data
| Brand | Quick |
| Part number | TSS11-1.2D |
| Tip series | TSS11 |
| Style | straight |
| Tip shape | chisel |
| Tip width | 1.2 mm |
| Tip thickness | 0.8 mm |
| Overall length | 90 mm |
| Shank diameter | 3.3 mm / 3.5 mm |
| Temperature range with TS11 | 100 to 450 °C |
| Heat-up time with TS11 | 3 s from 20 °C to 300 °C |
| Temperature sensing | integrated thermocouple |
| Scope of delivery | 1 cartridge tip TSS11-1.2D |
| Compatibility | Quick TS11 soldering station |
| RoHS | compliant |
Application, scope of delivery and compatibility
Suited to soldering on pads, pins, connectors and printed circuit boards in repair, rework, prototyping and laboratory work. For very close pitch the 0.8 mm TSS11-0.8D is the narrower option, for heavier terminals the TSS11-1.6D. Delivery is one cartridge tip, which fits the Quick TS11 soldering station.
| Manufacturer Nr. | TSS11-1.2D |
|---|---|
| Manufacturer | Quick |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
