Kartuschen-Lötspitze TS1, gerade meißelförmig 1,6 mm (SS1-1.6D) - Quick SS1-1.6D

A chisel tip passes heat along its whole edge rather than through a single point. At 1.6 mm this SS1 tip covers the size range where most hand soldering actually happens, through-hole parts, pin headers and wire ends, and brings the joint up to temperature quickly without heating the neighbouring pads.

Features

• Edge width of 1.6 mm, the face sits flat on pad and lead and shortens the contact time at the joint.
• Straight version, the edge runs along the axis of the iron and stays in view as it is placed.
• Cartridge design with heater and sensor close behind the tip, so temperature recovers quickly after each joint.
• The cartridge is changed as a complete unit, shape and width are swapped without touching the heating element.
• RoHS compliant according to the manufacturer.

Technical data

Application, scope of delivery and compatibility

For electronics repair, rework and assembly on the QUICK TS1 cordless iron rated 10 W with a range of 100 to 420 °C. Scope of delivery, one soldering tip. It fits the cartridge holder of the TS1 only, further shapes in the SS1 series cover finer and wider work.
