Load Cell 10 kg - SAUTER CB 10-3Q1

For weight and compression-force measurement in demanding conditions, the SAUTER CB 10-3Q1 carries up to 10 kg rated load: a bending and shear beam load cell in stainless steel, legal-for-trade as an OIML R60 class C3 component.

Benefits

• Legal-for-trade component: OIML R60 class C3, 3000 divisions (e), Y value 10000
• Durable housing: stainless steel for demanding environments
• Wide temperature range: use from -30 to 70 deg C
• Ready to fit: 3 m cable, 4-wire connection, compression loading
• Optional: accuracy class OIML R60 C6 or Ex version on request

Technical data

• Rated load (Max): 10 kg
• Accuracy class: OIML R60 class C3, 3000 e, Y value 10000
• Design: bending and shear beam load cell
• Material: stainless steel
• Force direction: compression
• Ambient temperature: -30 to 70 deg C
• Dimensions (diameter x height): 41,5 x 120 mm
• Cable length: 3 m
• Connection: 4-wire
• Net weight: 0,50 kg
• On request: accuracy class OIML R60 C6 or Ex version

Applications

Suited to platform, hopper and floor scales and other weighing devices in industry and manufacturing, the chemical industry, food and pharma, building materials, and logistics and packaging.

Compliance and origin

OIML R60 class C3. EAN 4045761220690, customs tariff number 84239010, country of origin Spain.
