Load Cell 1500 kg - SAUTER CT 1500-3Q1

The SAUTER CT 1500-3Q1 picks up compression forces up to 1500 kg directly in platform scales, hopper scales and floor-recessed scales. Its stainless steel shear beam delivers repeatable readings to OIML class C3 with 3000 e, even under harsh operating conditions.

Benefits

• Legal-for-trade resolution (OIML C3, 3000 e): traceable weighing at a Y-value of 10000.
• Stainless steel shear beam: corrosion-resistant sensing body for chemical, food and wet environments.
• Wide temperature range (-30 bis 70 °C): reliable operation from cold zones to warm halls.
• Rated capacity 1500 kg in compression: sized for platform, hopper and floor scales.
• 6-wire sense technology: dedicated sense lines compensate long cable runs and keep accuracy stable over the 5 m lead.

Technical data

• Capacity (Max): 1500 kg
• OIML class: C3
• Resolution (verifiable): 3000 e
• Y-value: 10000
• Force direction: compression
• Operating temperature: -30 bis 70 °C
• Cable length: 5 m
• Load cell connection: 6-wire
• Net weight: 1,00 kg
• Gross weight: 1,2 kg

Applications

Typical uses include industry and manufacturing, the chemical industry, food and pharma, the building materials industry as well as logistics and packaging.

Compliance and origin

EAN 4045761222236, customs tariff code 84239010, country of origin Spain.
