Load Cell 500 kg - SAUTER CB 500-3Q1

The SAUTER CB 500-3Q1 measures weight and compression forces up to 500 kg and forms the basis for verifiable platform, hopper or floor scales. The sealed stainless housing withstands harsh operating conditions.

Benefits

• Verifiable, class C3 (3000 e): suited to building legal-for-trade scales up to 500 kg
• Stainless steel: sealed body for chemical, food and humid environments
• Wide temperature range: operation from -30 °C to 70 °C
• Bending and shear-beam design: for platform, hopper and floor scales
• 3 m cable, 4-wire connection: integrates directly into existing indicators

Technical data

• Weighing range (max): 500 kg
• Operating temperature: -30 °C to 70 °C
• Dimensions (Ø×H): 41,5×120 mm
• Accuracy class (OIML): C3
• Resolution (verifiable): 3000 e
• Y value: 10000
• Force direction: Compression
• Cable length: 3 m
• Connection: 4-wire
• Net weight: 0,50 kg

Applications

Used in industry and manufacturing, the chemical industry, food and pharma, the building-materials sector and in logistics and packaging, wherever weighing or compression measurement takes place under harsh conditions.

Compliance and origin

Class C6 to OIML R60 and an Ex version are available on request. EAN 4045761220737. Customs tariff code 84239010. Country of origin Spain.
