Scale Kit 1500 kg - SAUTER CW 1500
The SAUTER CW 1500 is a scale-building kit with type approval for custom floor scales up to 1500 kg. Four CT 500-3P2 load cells rated IP67 and a CJ P4PG junction box make it ready for harsh, damp industrial use. Ideal for platform, hopper and silo scales.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
To build a floor scale up to 1500 kg yourself while weighing in a legally compliant way, reach for the SAUTER CW 1500 kit with type approval. Its four load cells and junction box are matched to each other and designed for harsh, damp industrial use.
Benefits
- With type approval: accuracy class III for legally compliant weighing in trade and industry.
- Moisture-proof: four CT 500-3P2 load cells rated IP67 to EN 60529.
- Tested cells: accuracy to OIML R60 C3, nickel-plated steel, rated output 3 mV/V.
- Sturdy junction box: CJ P4PG in a die-cast aluminium housing, IP65.
- Freely combinable: suitable for platform, hopper and silo scales, expandable with indicators such as KFS-TM, YKV or CE HS.
Applications
The CW 1500 is used in machinery and plant construction, in logistics and packaging, in the food industry, in maintenance and workshop, for tank and silo weighing, in the chemical industry and in pharmaceutical applications.
Compliance and origin
Load cells with accuracy to OIML R60 C3, protection to EN 60529, type approval for accuracy class III. EAN 4045761256460, customs tariff number 84231090, country of origin China.
Technical data
| Weighing range (max) | 1500 kg |
|---|---|
| Accuracy class | III |
| Weighing system | strain gauge |
| Load cells | 4 x CT 500-3P2, IP67, nickel-plated steel, 3 mV/V |
| Junction box | CJ P4PG, die-cast aluminium, IP65 |
| Load cell connection | 6-wire |
| Net weight | 6 kg |
| Weight | 7 kg |
| Manufacturer | Sauter |
| Manufacturer Nr. | CW 1500 |
| EAN | 4045761256460 |
| HS-Code | 84231090 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Certification | IEC 60529 |
| Wägebereich max (g) | 1500000 |
| Verification class | III |
