Scale Kit 9000 kg - SAUTER CW 9000

If you build your own floor scales for industry, vehicle construction or agriculture, the SAUTER CW 9000 gives you a complete load cell set with type approval: four cells for 9000 kg rated load plus junction box and wiring for legally compliant class III weighing.

Benefits

• Free scale building: suited to platform, hopper, silo and floor-recessed scales in your own dimensions.
• Load cells to OIML R60 C3: four CT 3000-3P2 cells in nickel-plated steel, rated output 3 mV/V.
• Built for damp settings: load cells with IP67 dust and splash protection to EN 60529.
• Prepared wiring: CJ P4PG junction box in a die-cast aluminium housing rated IP65.
• Type approval: the basis for building verifiable class III scales.

Technical data

• Capacity (Max): 9000 kg
• Accuracy class: III
• Weighing system: strain gauge
• Load cells: 4 × SAUTER CT 3000-3P2, OIML R60 C3
• Load cell protection: IP67 to EN 60529
• Junction box: SAUTER CJ P4PG, IP65
• Load cell connection: 6-wire
• Net weight: 12 kg

Applications

The kit suits machine and plant construction, logistics and packaging, the food industry, maintenance and workshop, container and silo weighing as well as chemical and pharmaceutical uses. For a readout it pairs with SAUTER indicators such as KFS-TM, YKV or CE HS.

Compliance and origin

EAN 4045761256545, customs tariff number 84231090, country of origin China.
