Scale Kit 600 kg - SAUTER CW 600RKFN

The SAUTER CW 600RKFN provides the weighing technology for custom scales up to 600 kg in a particularly hygienic design. Its four CB 200-3Q1 load cells are made of stainless steel and sealed to IP68/IP69K against dust and high-pressure cleaning. The CW 600RKFN version adds an LCD display for direct weight readout.

Benefits

• Stainless CB 200-3Q1 load cells: hygienic for food and outdoor use.
• High-pressure rated IP68/IP69K: sealed against dust, moisture and cleaning jets.
• Accuracy class III: for rated capacities up to 600 kg.
• Stainless junction box CJ X467: corrosion-free housing rated IP67.
• Versatile: from agriculture to municipal vehicles.
• Integrated LCD display: direct weight readout without a separate indicator.

Technical data

• Weighing range (max): 600 kg
• Accuracy class: III
• Weighing system: strain gauge
• Load cells: 4 x SAUTER CB 200-3Q1
• Load cell protection: IP68/IP69K
• Load cell material: stainless steel
• Rated output: 3 mV/V
• Junction box: SAUTER CJ X467, protection IP67
• Display: LCD
• Load cell connection: 4-wire
• Net weight: 6 kg

Applications

The kit suits machine and plant engineering, logistics and packaging, the food industry, maintenance and workshops, container and silo weighing, the chemical industry and pharmaceutical applications. The stainless design also fits weighing systems on fertiliser spreaders and municipal vehicles.

Compliance and origin

EAN 4045761256675. Customs tariff code 84231090. Country of origin: China.
