Scale Kit 6000 kg - SAUTER CW 6000R

For scales that face moisture and frequent cleaning, the SAUTER CW 6000R supplies four CT 2000-3Q1 load cells in alloy steel rated IP68/IP69K. At up to 6000 kg rated capacity, it suits platform, silo or floor scales that must withstand high-pressure washdown.

Benefits

• High-pressure rated IP68/IP69K: CT 2000-3Q1 load cells in alloy steel for wet areas and washdown.
• Accuracy class III (OIML R60 C3): a metrologically sound basis up to 6000 kg.
• 6-wire technology, 2 mV/V: stable signal transmission even over long cable runs.
• Stainless junction box CJ X467: corrosion-free housing rated IP67.
• Freely combinable: for platform, hopper, silo and floor scales.

Technical data

• Weighing range (max): 6000 kg
• Accuracy class: III
• Weighing system: strain gauge
• Load cells: 4 x SAUTER CT 2000-3Q1
• Load cell protection: IP68/IP69K
• Load cell material: alloy steel
• Rated output: 2 mV/V
• Junction box: SAUTER CJ X467, protection IP67
• Load cell connection: 6-wire
• Net weight: 9 kg

Applications

The kit suits machine and plant engineering, logistics and packaging, the food industry, maintenance and workshops, container and silo weighing, the chemical industry and pharmaceutical applications.

Compliance and origin

EAN 4045761256644. Customs tariff code 84231090. Country of origin: China.
