Plug for FS measuring cells up to 250 kN, mounted and adjusted - SAUTER FS 408
Plug for connecting an additional measuring cell up to 250 kN to the SAUTER FS 2 and FS 4 digital force gauges. Mounting on the measuring cell and two-point adjustment up to 250 kN are included. Serial number, maximum load and adjustment values are stored on the memory chip inside the plug.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The SAUTER FS 408 connects a further measuring cell up to 250 kN to a force gauge of the SAUTER FS series. The plug is mounted on the measuring cell and adjusted together with it at the factory. The cell's characteristic data are then held on the integrated memory chip.
Advantages
- Ready to use: mounting on the measuring cell and two-point adjustment up to 250 kN included
- Data in the plug: serial number, maximum load and adjustment values are written to the memory chip
- Several cells per gauge: adds a measuring cell to SAUTER FS 2 and FS 4
- Matching cells: measuring cells of the SAUTER CR and SAUTER CS series
Conformity and origin
EAN 4045761237162. Warranty 24 months.
Technical data
| Tensile/compressive force (max) | 250 kN |
|---|---|
| Net weight | approx. 0.05 kg |
| Suitable for | SAUTER FS 2 and FS 4 force gauges |
| Weight | 0.05 kg |
| Manufacturer | Sauter |
| EAN | 4045761237162 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
- Plug for connecting a measuring cell
- Mounting of the plug on the measuring cell
- Two-point adjustment up to 250 kN
- Transfer of serial number, maximum load and adjustment values to the memory chip
