Digital Force Gauge - SAUTER FS 4-50
The SAUTER FS 4-50 is a digital premium force gauge with an integrated load cell and a connection for up to four external sensors. It measures tension and compression up to 50 N at 0,01 N readability and guards the cell with 150% overload protection.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For tension and compression testing up to 50 N straight on the part, the SAUTER FS 4-50 combines an integrated load cell with a connection for up to four external sensors, so one instrument covers everything from a quick hand test to a fixed test stand. Readability is 0,01 N.
Benefits
- Two measuring paths in one instrument: integrated load cell plus a connection for up to four external cells.
- Fine resolution: 0,01 N readability at a 50 N range.
- Overload protection: up to 150% of the range protects the load cell.
- Clear operation: 3.5 inch touchscreen with track, peak-hold and tolerance functions at a 1000 Hz sampling rate.
- Data and storage: USB interface for data output plus 16 GB of internal memory.
- Mobile and stationary: mounts on SAUTER test stands and ships in a system case (systainer T-LOC).
Applications
The instrument is used in test laboratories, in research and development, in the automotive industry, in maintenance and servicing and in plastics engineering.
Compliance and origin
EAN 4045761237049, customs tariff code 90248000, country of origin Germany.
Technical data
| Measuring range (Max) | 50 N |
|---|---|
| Readability (d) | 0,01 N |
| Force directions | tension and compression |
| Overload protection | 150% of Max |
| Measuring frequency | 1000 Hz |
| Display | 3.5 inch touchscreen |
| Internal memory | 16 GB |
| Interface | USB |
| Power | Li-Ion battery and mains adapter |
| Dimensions (W x D x H) | 71 x 31 x 180 mm |
| Housing | plastic |
| Net weight | 0,45 kg |
| Weight | 1.4 kg |
| Manufacturer | Sauter |
| EAN | 4045761237049 |
| HS-Code | 90248000 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Material | Plastic |
Accessories
Show 52 more items
Plug for FS measuring cells of the SAUTER CD series, mounted and adjusted - SAUTER FS 401
Item KER-FS 401
Plug for FS measuring cells up to 500 N, mounted and adjusted - SAUTER FS 402
Item KER-FS 402
Plug for FS measuring cells up to 2 kN, mounted and adjusted - SAUTER FS 403
Item KER-FS 403
Plug for FS measuring cells up to 5 kN, mounted and adjusted - SAUTER FS 404
Item KER-FS 404
Plug for FS measuring cells up to 20 kN, mounted and adjusted - SAUTER FS 405
Item KER-FS 405
Plug for FS measuring cells up to 50 kN, mounted and adjusted - SAUTER FS 406
Item KER-FS 406
Plug for FS measuring cells up to 120 kN, mounted and adjusted - SAUTER FS 407
Item KER-FS 407
Plug for FS measuring cells up to 250 kN, mounted and adjusted - SAUTER FS 408
Item KER-FS 408
Bending ring load cell 60 kg / 600 N, stainless steel, C3 - SAUTER CR 60-3P1
Item KER-CR 60-3P1
Bending Ring Load Cell 130 kg, 1.3 kN, Stainless Steel - SAUTER CR 130-3P1
Item KER-CR 130-3P1
Bending Ring Load Cell 500 kg, 5 kN, Stainless Steel - SAUTER CR 500-3P1
Item KER-CR 500-3P1
Bending Ring Load Cell 250 kg, 2.5 kN, Stainless Steel - SAUTER CR 250-3P1
Item KER-CR 250-3P1
Bending Ring Load Cell 2000 kg, 20 kN, Stainless Steel - SAUTER CR 2000-3P1
Item KER-CR 2000-3P1
