Aluminium upright profile set ESD for QuatreX, WxH 1789x1200 mm, 1836 mm frame - Treston AL2X180QX
Anodized aluminium upright profile set for mounting accessories on the Treston QuatreX workbench with a 1836 mm wide frame. Two vertical profiles and one height-adjustable cross profile carry up to 150 kg. ESD-safe with a 10-year warranty.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Aluminium accessories can only be attached to a QuatreX workbench with upright profiles in place. This set forms a 1789 x 1200 mm (WxH) frame above the worktop to hold lights, shelves, bin rails and other accessories, with a permitted load of 150 kg.
Key features
- Set of 2 vertical profiles and 1 horizontal profile, the cross profile is height-adjustable
- Anodized aluminium, lightweight and corrosion-resistant
- 150 kg load capacity for the accessory structure
- Fits the 1836 mm wide frame of the Treston QuatreX (module 180)
- ESD-safe for electrostatic protected workstations
Technical data
| Dimensions WxDxH | 1789 x 55 x 1200 mm |
|---|---|
| Contents | 2 vertical profiles, 1 horizontal profile |
| Material | Anodized aluminium |
| Colour | Light grey |
| Max load | 150 kg |
| ESD | Yes |
| Compatible with | Treston QuatreX, frame width 1836 mm, module 180 |
| Warranty | 10 years |
| Weight | 8.8 kg |
| Manufacturer | Treston |
| Manufacturer Nr. | AL2X180QX |
| EAN | 6416763098361 |
| HS-Code | 94032080 |
| GPSR manufacturer information | Treston Deutschland GmbH, Friedrich-Ebert-Damm 143, DE-22047 Hamburg |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Finland |
| Sales unit | 1 |
| Height | 1200 |
| Width | 1789 |
| Depth | 55 |
| ESD version | ESD (antistatic) |
| Load capacity (kg) | 150 |
The set is the base for an individually equipped assembly or test station. Accessories are added as needed and can be extended later without rebuilding the bench.
