LED high bay luminaire ACANEO HIAL 14000/850/W/DALI, 90 W, 15,000 lm, 88° wide beam, DALI dimmable - Waldmann 113547000-00737125

For workshops, assembly areas and halls of medium height, the ACANEO HIAL 14000/850/W/DALI delivers approx. 15,000 lm from only approx. 90 W. At approx. 166 lm/W this output level gets the most light out of every watt, which cuts running costs over long operating hours. The 88° wide-beam optic spreads the light across the area and suits open zones and lower mounting heights. Its DALI ballast allows continuous dimming and integration into a lighting management system.

Benefits

• 88° wide beam optic: uniform lighting of large, open hall areas
• Continuously dimmable via DALI, for daylight or presence control with a matching sensor
• 5000 K for a cool, high-contrast impression in visual and inspection tasks, CRI ≥ 80, chromaticity tolerance < 3 SDCM
• IP65, protection class I and operation at ambient temperatures from -30 °C to 70 °C, also for unheated halls and cold areas

Applications

• Production halls and assembly areas
• Open storage and logistics areas
• Workshops and maintenance areas
• Goods receiving and inspection areas with visual checks
• Halls with lighting management or zone control

Installation and accessories

• Fastening available separately: ceiling bracket, 1-point suspension, trapezoidal hanger or wire rope with wire rope holder
• Mains connection via built-in plug RST 20i5, junction box RST 20i5 and safety glass available as accessories
• Sensors with surface-mounting adaptor and Netcomposer control (NCR) from the ACANEO accessories
