LED high-bay luminaire ACANEO HIAL 14000/840/N/DALI, 15,000 lm, 4000 K, 48°, DALI - Waldmann 113547000-00737034

Halls where lighting is to be adjusted to demand or integrated into a lighting control system need a dimmable luminaire. The ACANEO HIAL 14000/840/N/DALI delivers approx. 15,000 lm at 90 W, around 166 lm/W, is continuously dimmable via DALI and focuses the light with a 48° beam angle.

Benefits

• Aluminium housing, powder-coated in white aluminium, IP65 and protection class I, usable from -30 °C to 70 °C
• Narrow-beam symmetric optics with 48°, UGR ≤ 19, luminance L65 ≤ 4200 cd/m²
• LED life L80B50 60,000 h, chromaticity tolerance < 3 SDCM, CRI ≥ 80
• Plug-in connection via RST 20i5 connector with matching junction box
• High luminous flux per luminaire: approx. 15,000 lm at 90 W, 166 lm/W luminous efficiency
• Continuously dimmable via DALI, can be integrated into the Netcomposer (NCR) control with DALI presence and daylight sensors

Applications

• Production halls with daylight and presence-based lighting control
• Warehouse and logistics halls
• Halls exposed to coolants, oils or welding fumes (resistant according to the manufacturer)

Installation and accessories

• Fastening available separately: ceiling mounting bracket (adjustable), 1-point suspension with wire ropes, wire rope holder and trapezoidal hanger with M8 thread
• Mains connection via RST 20i5 connector, RST 20i5 junction box as accessory
• Safety glass panels 585 x 480 mm and 480 x 405 mm available as accessories
• Netcomposer (NCR) control for 2 x 64 DALI devices, DALI daylight sensor and presence sensor with 10 m working height, surface-mounting adapter
