LED tube luminaire RL70LE-120 N, 22-26 V DC, 4700 lm, 1490 mm, polycarbonate - Waldmann 113726000-00806239

Name: LED tube luminaire RL70LE-120 N, 22-26 V DC, 4700 lm, 1490 mm, polycarbonate - Waldmann 113726000-00806239
Brand: Waldmann
SKU: WAL-113726000-00806239
Price: 579.60 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED tube luminaire RL70LE-120 N in a clear polycarbonate tube, 1490 mm long, 4700 lm at 62.5 W and 22-26 V DC. IP67 rated for use on machines in food-related areas.

Net

€579.60

excl. VAT

Item WAL-113726000-00806239

Manufacturer no. 113726000-00806239

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The RL70LE-120 N puts 4700 lm onto a light output length of 1436 mm, and its clear polycarbonate tube is designed for areas close to food products. It runs directly on the 22-26 V DC machine voltage, with no operating device inside the luminaire.

Benefits

4700 lm at 62.5 W power consumption, luminous efficiency 74 lm/W, 5000 K neutral white, CRI ≥ 80
Clear polycarbonate tube with IP67 protection for areas close to food products
Diffuser and 100° beam angle for even light across 1436 mm of light output, luminance L65 ≤ 14,000 cd/m²
Operates on 22-26 V DC machine voltage in protection class III, connected via ST16/2 BS connector

Applications

Machines in areas close to food products
Packaging systems
Food processing systems

Installation and accessories

Mounting with pipe clamp (accessory)
Mains connection via ST16/2 BS built-in plug, screwed cable gland on side part A
Matching luminaire brackets, also with rubber profile or in stainless steel
For mains operation: operating device 100-240 V / 24 V DC 100 W or constant voltage operating device 220-240 V / 24 V DC

Technical data

Manufacturer article no.	113726000-00806239
Order number	00806239
EAN	4013330140243
Connected load	22-26 V, DC
Work equipment	Without
Power consumption	approx. 62.5 W
Luminous flux	approx. 4700 lm
Luminous efficiency	approx. 74 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 5000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 99 %
Beam angle	100°
Glare control	Diffuser
Light source	LED
Chromaticity tolerance LED	< 4 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 14,000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP 67, III
Technology	Switchable
Operation	External
Housing	Polycarbonate (PC), clear
Light source cover	Polycarbonate (PC)
Mains lead	Built-in plug, ST16/2 BS
Fastening	Pipe clamp (accessory)
Light output	D = 1436 mm
Side part	A with screwed cable gland
Maximum ambient temperature	40 °C
Weight without/incl. packaging	3.93 kg / approx. 4.5 kg
Dimensions (dimensional drawing)	A=1490 mm
Packaging dimensions	1700 mm x approx. 90 mm x 90 mm
Tube diameter	70 mm
Weight	4.5 kg
Manufacturer	Waldmann
Manufacturer Nr.	113726000-00806239
HS-Code	94054239
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Farbe	Polycarbonat, glasklar
Luminous flux (lumen)	4700 lm
Power (W)	62,5 W
Colour rendering (Ra)	Ra 80
Overall length [mm]	1490
Operating voltage	22-26 V
Series	RL 70 LE
Protection class (IP)	IP67
