TUBELED_25 RGB-W surface-mounted machine light 1040 mm, 100°, 24V DC - LED2WORK 154690-01

The TUBELED_25 RGB-W combines work lighting and status signalling in a single luminaire. RGB-W cluster LEDs produce 4600 lm of neutral-white light at 5000K to illuminate work areas while also showing clearly distinguishable signal colours for machine states, designed for the IoT generation of technical systems.

Key benefits

• Illumination and signalling in one device, RGB-W LED chips in clusters
• 4600 lm white light at 5000K (3-step MacAdam) and colour rendering Ra >85
• Very flat build of only approx. 23 mm for tight installation spaces
• IP67 protection, dust- and liquid-tight thanks to aluminium housing and hardened glass
• Long service life of over 100,000 h (L80/B10)

Technical data

• Model: TUBELED_25 RGB-W
• Design: surface-mounted LED light
• Light source: SMD RGB-W cluster LED
• Power white: ~28,8 W, luminous flux 4600 lm
• Power red: ~8,64 W, 552 lm; green: ~5,76 W, 1008 lm; blue: ~8,64 W, 336 lm
• Light colour white: 5000K (3-step MacAdam), Ra >85
• Supply voltage: 24 V DC -10 %+7 % (RGB), 24 V DC ±10 % (W)
• Connection: M8 B-coded, 5-pole
• Protection rating: IP67, protection class III
• Beam angle: 100°, glare control via diffuse toughened single-pane glass
• Operating temperature: -30 °C to +55 °C
• Service life: > 100,000 h (L80/B10)
• Material: aluminium housing, safety glass cover
• Dimensions: length 1040 mm, approx. 23 mm x approx. 28 mm, weight 700 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529)
• Made in: Germany

Applications

Lighting and state signalling on CNC machines, machine tools and automation systems as well as in infrastructure areas, especially where a flat build and tight installation spaces are required.

Mounting accessories available as an option. Made in Germany.
