LED continuous-row gear tray TAUREO TRG 12000/840/NB/DA/1686/7/WS, 12,000 lm, 35° - Waldmann 227229149-00817691

The TAUREO TRG 12000/840/NB/DA/1686/7/WS gear tray equips continuous rows in industrial halls with approx. 12,000 lm at 78.5 W, which corresponds to approx. 152 lm/W. The 35° beam angle concentrates the light downwards, delivering it to the working level even from high mounting positions or into narrow aisles.

Benefits

• Luminous flux approx. 12,000 lm: a powerful step at 78.5 W for greater mounting heights and high illuminance demands at the work surface
• Luminous efficiency of approx. 152 lm/W lowers energy use in continuous operation
• DALI ballast, continuously dimmable, for lighting management and daylight control via the bus
• Neutral white 4000 K, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for a uniform appearance along the row
• LED life of L80B50 100,000 h reduces maintenance work at height

Applications

• High-bay warehouses and narrow racking aisles
• Tall production halls with high mounting heights
• Targeted lighting of machine lines and conveyor sections

Installation and accessories

• Gear tray for insertion into the TAUREO TRT mounting rail, type code 1686/7 (7-pole, 1686 mm)
• Ceiling mounted, housing in white painted sheet metal, clear acrylic (PMMA) cover
• Mains connection 220-240 V AC, 50/60 Hz, IP40, protection class I, weight approx. 2.4 kg without packaging
