LED continuous row luminaire TAUREO TRG 12000/840/WB/DA/1686/7/WS/EL3, 12,000 lm, 95° wide beam, 3 h emergency light

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED continuous row luminaire TAUREO TRG 12000/840/WB/DA/1686/7/WS/EL3, 12,000 lm, 95° wide beam, 3 h emergency light - Waldmann 227229189-00817696

Name: LED continuous row luminaire TAUREO TRG 12000/840/WB/DA/1686/7/WS/EL3, 12,000 lm, 95° wide beam, 3 h emergency light - Waldmann 227229189-00817696
Brand: Waldmann
SKU: WAL-227229189-00817696
Price: 474.30 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Gear tray for the TAUREO continuous row system with 12,000 lm at 78.5 W, i.e. 152 lm/W, and a 95° beam angle (wide beam). A battery keeps emergency light available for 3 hours during a power failure. Intended for ceiling lighting in halls, production and warehouses.

Net

€474.30

excl. VAT

Item WAL-227229189-00817696

Manufacturer no. 227229189-00817696

Question about this item

Datasheet (PDF) 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A hall should be evenly bright and use little energy in operation. The TAUREO TRG 12000 reaches 152 lm/W and delivers 12,000 lm at 78.5 W, dimmable via DALI. It includes an emergency light battery for 3 hours.

Benefits

12,000 lm at 78.5 W, luminous efficiency 152 lm/W
Wide 95° optics spread the light across the floor, even at lower mounting heights.
Digitally dimmable DALI ballast for daylight and presence control via the building management system
Neutral white 4000 K, CRI ≥ 80, chromaticity tolerance < 3 SDCM, LED life L80B50 100,000 h
Emergency light with 3-hour battery built into the gear tray
Operation at -20 to 35 °C ambient temperature

Applications

Production and assembly halls
Warehousing and logistics
Workshops and manufacturing areas
Areas where escape routes must stay lit during a power failure

Installation and accessories

Ceiling mounted in the TAUREO continuous row system
TAUREO TRT mounting rail available separately

Technical data

Manufacturer item no.	227229189-00817696
Order number	00817696
EAN	4013330200763
Connected load	220-240 V, AC, 50 Hz, 60 Hz, IK02
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 78.5 W
Luminous flux	approx. 12,000 lm
Luminous efficiency	approx. 152 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	95 °
Glare control	Optics
Light source	LED
Life expectancy LED	L80B50 100,000 h
Chromaticity tolerance LED	< 3 SDCM
EPREL number of lightsources	769336, 769343
At-risk group	RG0/1
Luminance (L65)	≤ 13,000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Housing	Sheet metal, Painted, White
Light source cover	Acrylic (PMMA), Clear
Fastening	Ceiling mounted
Ambient temperature min./max	-20 °C / 35 °C
Weight without/incl. packaging	2.9 kg / approx. 3.4 kg
Packaging dimensions	1770 mm x approx. 222 mm x 95 mm
Special features	Emergency light with 3-hour battery, Wide Beam
Weight	3.4 kg
Manufacturer	Waldmann
Manufacturer Nr.	227229189-00817696
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	12000 lm
Power (W)	78,5 W
Colour rendering (Ra)	Ra 80
Operating voltage	220-240 V
Series	TAUREO
Protection class (IP)	IP40
