LED continuous row luminaire TAUREO TRG 16000/840/NB/DA/1686/7/WS/EL3, 16,000 lm, 35° narrow beam, 3 h emergency light

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED continuous row luminaire TAUREO TRG 16000/840/NB/DA/1686/7/WS/EL3, 16,000 lm, 35° narrow beam, 3 h emergency light - Waldmann 227229239-00817701

Name: LED continuous row luminaire TAUREO TRG 16000/840/NB/DA/1686/7/WS/EL3, 16,000 lm, 35° narrow beam, 3 h emergency light - Waldmann 227229239-00817701
Brand: Waldmann
SKU: WAL-227229239-00817701
Price: 532.95 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Gear tray for the TAUREO continuous row system with 16,000 lm at 99 W, i.e. 161 lm/W, and a 35° beam angle (narrow beam). A battery keeps emergency light available for 3 hours during a power failure. Intended for ceiling lighting in halls, production and warehouses.

Net

€532.95

excl. VAT

Item WAL-227229239-00817701

Manufacturer no. 227229239-00817701

Question about this item

Datasheet (PDF) 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A hall should be evenly bright and use little energy in operation. The TAUREO TRG 16000 reaches 161 lm/W and delivers 16,000 lm at 99 W, dimmable via DALI. It includes an emergency light battery for 3 hours.

Benefits

16,000 lm at 99 W, luminous efficiency 161 lm/W
Narrow 35° optics concentrate the light for high mounting heights and narrow aisles.
Digitally dimmable DALI ballast for daylight and presence control via the building management system
Neutral white 4000 K, CRI ≥ 80, chromaticity tolerance < 3 SDCM, LED life L80B50 100,000 h
Emergency light with 3-hour battery built into the gear tray
Operation at -20 to 35 °C ambient temperature

Applications

Production and assembly halls
Warehousing and logistics, especially high rack aisles
Workshops and manufacturing areas
Areas where escape routes must stay lit during a power failure

Installation and accessories

Ceiling mounted in the TAUREO continuous row system
TAUREO TRT mounting rail available separately

Technical data

Manufacturer item no.	227229239-00817701
Order number	00817701
EAN	4013330200817
Connected load	220-240 V, AC, 50 Hz, 60 Hz, IK02
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 99 W
Luminous flux	approx. 16,000 lm
Luminous efficiency	approx. 161 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	35 °
Glare control	Optics
Light source	LED
Life expectancy LED	L80B50 100,000 h
Chromaticity tolerance LED	< 3 SDCM
EPREL number of lightsources	769339, 769346
At-risk group	RG0/1
Luminance (L65)	≤ 32,000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Housing	Sheet metal, Painted, White
Light source cover	Acrylic (PMMA), Clear
Fastening	Ceiling mounted
Ambient temperature min./max	-20 °C / 35 °C
Weight without/incl. packaging	2.9 kg / approx. 3.4 kg
Packaging dimensions	1770 mm x approx. 222 mm x 95 mm
Special features	Emergency light with 3-hour battery, Narrow Beam
Weight	3.4 kg
Manufacturer	Waldmann
Manufacturer Nr.	227229239-00817701
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	16000 lm
Power (W)	99 W
Colour rendering (Ra)	Ra 80
Operating voltage	220-240 V
Series	TAUREO
Protection class (IP)	IP40
