LED continuous-row gear tray TAUREO TRG 16000/840/WB/DA/1686/7/WS/EL3, 16,000 lm, 95°, emergency light 3 h - Waldmann 227229249-00817702

For anyone who wants hall lighting and emergency lighting in a single line, the TAUREO TRG 16000/840/WB/DA/1686/7/WS/EL3 gear tray provides both: approx. 16,000 lm of working light at 99 W and an integrated 3-hour battery for emergency operation. The 95° wide-beam optic spreads the light evenly across the area and allows wider row spacing at lower ceiling heights.

Benefits

• Luminous flux approx. 16,000 lm at 99 W
• Integrated emergency light with 3-hour battery, so no separate emergency luminaire is needed at this position
• Luminous efficiency of approx. 161 lm/W lowers energy use in continuous operation
• DALI ballast, continuously dimmable, for lighting management and daylight control via the bus
• Neutral white 4000 K, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for a uniform appearance along the row

Applications

• Workshops and workbenches with lower ceiling heights
• Assembly and inspection stations needing even coverage
• Light lines along escape routes in halls and warehouses

Installation and accessories

• Gear tray for insertion into the TAUREO TRT mounting rail, type code 1686/7 (7-pole, 1686 mm)
• Ceiling mounted, housing in white painted sheet metal, clear acrylic (PMMA) cover
• Mains connection 220-240 V AC, 50/60 Hz, IP40, protection class I, weight approx. 2.9 kg without packaging
