Torque screwdriver TorqueVario-S ESD 0.04-0.46 Nm for ESD-sensitive components - Wiha 36851

Uncontrolled electrostatic discharge during work on electronic components can permanently destroy sensitive parts. The TorqueVario-S ESD combines controlled torque fastening with ESD protection per IEC 61340-5-1. The dissipative handle made of conductive plastic has a surface resistance of 10^6 to 10^9 ohms and channels electrostatic energy away in a controlled manner. The continuously adjustable torque from 0.04 to 0.46 Nm is set using the integrated numeric scale and the included Torque-Setter adjusting tool.

Benefits

• ESD-safe handle per IEC 61340-5-1: maximum protection for electrostatic-discharge-sensitive components
• Surface resistance 10^6 - 10^9 ohms: controlled, safe dissipation of electrostatic energy
• Continuously adjustable torque 0.04 - 0.46 Nm: wide application range in precision mechanics
• Click signal on release: audible and tactile feedback prevents over-tightening
• Release accuracy ±6 % (DIN EN ISO 6789): process-safe torque documentation
• Compatible with Series 2859 blades and 1/4" bit holder: easy to extend

Technical data

• Torque range: 0.04 - 0.46 Nm (accuracy ±6 % from 0.1 Nm)
• Tolerance: ±10 % in lower range
• Hexagon head: 4.0 mm
• Handle diameter: 23 mm, handle length: 127 mm
• Surface resistance: 10^6 - 10^9 ohms
• Product dimensions: 195 x 35 x 35 mm (L x W x D)
• Standards: DIN EN ISO 6789, IEC 61340-5-1
• Contents: ESD torque handle, Torque-Setter, robust box, works inspection protocol
• ESD: Yes

Applications

For accurate torque fastening on ESD-sensitive components in electronics manufacturing, PCB assembly and equipment maintenance. For use with Wiha Torque 4 mm interchangeable blades (Series 2859) or 1/4" bits. Made in Germany.
