Torque screwdriver iTorque with digital scale 40-150 Ncm (0.4-1.5 Nm) - Wiha 36886
Digital torque screwdriver with large display, continuously adjustable torque from 40 to 150 Ncm (0.4-1.5 Nm) and integrated calibration counter. Torque is set conveniently via the push button built into the handle; the calibration alarm reminds users after every 5,000 applications - ideal for testing equipment monitoring.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Wiha iTorque torque screwdriver combines digital setting convenience with reliable torque control. The large digital display shows the set value in Nm or in.lbs; units can be switched at the press of a button. The ergonomic plastic/metal compound handle with soft zones provides a secure grip. Release accuracy is ±6 % per DIN EN ISO 6789, and the integrated counter logs every activation for complete testing equipment documentation.
Benefits
- Large digital display: fast, reliable reading of the set Nm value
- Unit switching Nm/in.lbs and cNm/in.oz: versatile use
- Click Control: integrated counter documents every application
- Calibration alarm after 5,000 applications: timely reminder for calibration cycle
- Release accuracy ±6 % (DIN EN ISO 6789): process-safe documentation
- Universal bit holder (1/4"): accepts C 6.3 and E 6.3 bits
Applications
For controlled fastening in precision manufacturing, indexable insert changes and wherever calibration cycles must be monitored. Compatible with Wiha Torque 4 mm interchangeable blades (Series 2859). Made in Germany.
Technical data
| Torque range | 0.4 - 1.5 Nm (40 - 150 Ncm) |
|---|---|
| Tolerance | ±6 % |
| Hexagon head | 4.0 mm |
| Handle diameter | 34 mm, handle length: 134 mm |
| Product dimensions | 195 x 80 x 60 mm (L x W x D) |
| Power supply | 1 x button cell 3.0 V (35 mAh, not included) |
| Standard | DIN EN ISO 6789 |
| Note | battery replacement only possible via complete overhaul |
| ESD | No |
| Weight | 0.322 kg |
| Manufacturer | Wiha |
| Manufacturer Nr. | 36886 |
| EAN | 4010995368869 |
| HS-Code | 82054000 |
| GPSR manufacturer information | Wiha Werkzeuge GmbH Obertalstraße 3-7 DE-78136 Schonach www.wiha.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| Norm | DIN EN ISO 6789 |
