Quad rework tip of the SMTC series that reflows all four lead rows of a PLCC 28 package at once and releases the device from the board without tilting. The temperature is controlled inductively and needs no calibration. For the MX-H1-AVA, MX-RM3E hand pieces of the MX series.
Rework tip quad for PLCC 28 SMTC series - Metcal
METCAL
Original product
Net price (excl. VAT)
€89.50
Item
WL13777
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
ConditionNew
Article
WL13777
Frequently Bought Together
-
This Item:
€89.50
-
Rework tip hoof-shaped 2 x 11.6 mm, SMTC series - Metcal SMTC-0185
€57.44
-
Rework soldering tip slot for chip 1206/1210 SMTC series 357 °C - Metcal SMTC-002
€54.32
Total price
A PLCC 28 package carries leads on all four sides and is hard to desolder side by side without damage. This quad tip surrounds the device completely and melts every joint together.
Benefits
- Quad geometry matched to the PLCC 28 package
- All four lead rows are reflowed at the same time
- Protects pads and solder resist during component replacement
- Inductive heating of the Metcal SMTC series with fast thermal recovery
- For the MX-H1-AVA, MX-RM3E hand pieces of the MX series
Technical data
| Item no. | WL13777 |
| Model | SMTC-113 |
| Manufacturer | Metcal |
| Order unit | Piece |
| Product series | SMTC series |
| Tip shape | Quad |
| Compatible hand piece | MX-H1-AVA, MX-RM3E |
| Weight | 0.1 kg |
Applications
Component replacement on PLCC 28 packages in repair and prototype work, rework after the reflow process and fault analysis on populated assemblies.
Compatibility and scope of delivery
Compatible with the MX-H1-AVA, MX-RM3E hand pieces of the Metcal MX series. Scope of delivery: 1 rework tip cartridge SMTC-113.
| Manufacturer | Metcal |
|---|---|
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
