Conical soldering tip with 0.4 mm diameter, 7.9 mm length and a 30° bend for the Metcal STTC series. The bend keeps the hand piece out of the line of sight and reaches joints under overhanging components. Working temperature is a constant 412 °C.
Soldering tip conical bent 30° 0.4 x 7.9 mm STTC series - Metcal STTC-126
METCAL
Original product
Net price (excl. VAT)
€27.99
Item
WL13905
Manufacturer no.
STTC-126
ESD · IEC 61340-5-1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.STTC-126
ConditionNew
Article
WL13905
Frequently Bought Together
-
This Item:
€27.99
-
Soldering tip chisel 90 degrees 3 mm STTC series - Metcal STTC-013
€29.86
-
Soldering tip chisel 2.5 mm optimised geometry STTC series - Metcal STTC-136P
€27.99
Total price
Keep the view clear and still reach the joint: the 30° bent STTC-126 conical tip with 0.4 mm diameter and 7.9 mm length works at a constant 412 °C on Metcal STTC systems.
Benefits
- 30° bent tip for a clear view of the joint
- 0.4 mm diameter for fine leads and tight pitch
- Access under overhanging parts, connector shrouds and shields
- Constant 412 °C with no control lag on contact
- For MX-H1-AVA and MX-RM3E on MX-500, MX-5000 and MX-5200
Technical data
| item number | WL13905 |
| model | STTC-126 |
| manufacturer | Metcal |
| manufacturer item number | STTC-126 |
| order unit | piece |
| product series | STTC series |
| tip length | 7.9 mm |
| soldering tip diameter | 0.4 mm |
| tip shape | conical |
| tip alignment | bent |
| tip temperature | 412 °C |
| suitable hand piece | MX-H1-AVA, MX-RM3E |
| weight | 0.1 kg |
Applications
Useful for microscope work, for obstructed joints next to tall components and for rework inside already assembled devices.
Compatibility and scope of delivery
The cartridge fits the MX-H1-AVA and MX-RM3E hand pieces and therefore the Metcal MX-500, MX-5000 and MX-5200 systems. Delivery includes one soldering tip cartridge with integrated heater, order unit piece.
The closed, electrically conductive cartridge design and the grounded tip support soldering on ESD sensitive assemblies inside an EPA according to IEC 61340-5-1.
| Certification | IEC 61340-5-1 |
|---|---|
| Manufacturer Nr. | STTC-126 |
| Manufacturer | Metcal |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Series | STTC |
| Tip diameter/width [mm] | 0.400000 |
| Soldering tip shape | konisch |
