Soldering tip conical bent 30° 0.4 x 7.9 mm STTC series - Metcal STTC-826
Conical soldering tip of the STTC series with a 30° bend, 0.4 mm point, 7.9 mm length and 485 °C tip temperature. The bend reaches joints under low components and behind obstacles without holding the handpiece at a steep angle. For the Metcal MX-500, MX-5000 and MX-5200 systems.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Joints hidden under heat sinks or next to tall components are hard to reach with a straight tip. The Metcal STTC-826 is a conical soldering tip of the STTC series with a 30° bent alignment, 0.4 mm point, 7.9 mm length and 485 °C tip temperature.
Benefits
- 30° bend gives access to hidden and recessed joints
- Conical 0.4 mm diameter for fine pitch layouts and single leads
- Tip temperature 485 °C for ceramic substrates and high mass bonding
- Tip length 7.9 mm keeps the heat path short and the hand steady
- Compatible with the MX-500, MX-5000 and MX-5200 systems
Applications
Soldering in confined places under shields and heat sinks, work on ceramic substrates, touch up of connector contacts and repairs inside tight enclosures.
Compatibility and scope of delivery
The cartridge fits the MX-H1-AVA and MX-RM3E handpieces and runs on the MX-500, MX-5000 and MX-5200 soldering systems. Scope of delivery: one STTC-826 soldering tip.
Technical data
| Item number | WL26161 |
|---|---|
| Model | STTC-826 |
| Manufacturer | Metcal |
| Manufacturer item number | STTC-826 |
| Order unit | piece |
| Product series | STTC series |
| Tip length | 7.9 mm |
| Soldering tip diameter | 0.4 mm |
| Tip shape | conical |
| Tip alignment | bent 30° |
| Tip temperature | 485 °C |
| Suitable handpiece | MX-H1-AVA, MX-RM3E |
| Weight | 0.1 kg |
| Manufacturer Nr. | STTC-826 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Condition of article | New |
| Article authenticity | Original product |
| Tip diameter/width [mm] | 0.4 |
| Soldering tip shape | konisch |
| Series | STTC |
