Extraction nozzle DN50 length 310 mm aluminium - Alsident 1-5031
Anodised aluminium extraction nozzle for Alsident arms with a 50 mm tube diameter. At 310 mm it reaches across larger assemblies to the solder joint without having to reposition the arm. The shaped flare widens the capture zone in front of the opening.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Deeper work areas need a nozzle that reaches further than the arm itself. The Alsident 1-5031 is a 310 mm extraction nozzle for DN50 arms that removes fume locally at source while leaving access to the assembly clear.
Benefits
- 310 mm length for reach across larger boards and enclosures
- Capture directly at source with a modest airflow
- Shaped flare that widens the capture zone in front of the opening
- Tube in anodised aluminium with 10 μ layer thickness
- Matches the WSA-5LR, WSA-10LR and WSA-20LR extraction units
Applications
The nozzle is used for hand soldering and rework on larger assemblies, at test and repair benches and for dispensing or bonding. It is intended for fume and light vapours rather than heavy dust.
Compatibility and scope of delivery
The nozzle pushes onto Alsident extraction arms with a 50 mm tube diameter and matches the WSA-5LR, WSA-10LR and WSA-20LR device series. Delivery covers one extraction nozzle without arm and without extraction unit.
Technical data
| Item number | WL15455 |
|---|---|
| Model | 1-5031 |
| Manufacturer | Alsident |
| Manufacturer item number | 1-5031 |
| Length | 310 mm |
| Tube diameter | 50 mm |
| Material | Anodised aluminium tube, 10 μ layer thickness |
| Device series | WSA-5LR, WSA-10LR, WSA-20LR |
| Order unit | piece |
| Weight | 0.1 kg |
| Manufacturer Nr. | 1-5031 |
| HS-Code | 84219990 |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
